Specifications
The range in figures, from the manufacturer’s spec sheet and the shafts we’ve ordered. Every lift is then sized to its house.
StopsG+12G+23G+34
Floors servedG+1Ground and firstG+2Ground to secondG+3Ground to third
Shaft, as orderedG+1Made to measureG+210,450 × 900–1,420 × 1,500–1,520 mmG+313,498 × 900 × 1,500 mm
Landing doorG+1900 × 2,160 mmG+2900 or 1,265 × 2,160 mmG+3900 × 2,160 mm
Door openingG+1720 × 2,000 mmG+2720 or 1,085 × 2,000 mmG+3720 × 2,000 mm
Floor to floor, as orderedG+1Set to your houseG+23,380 and 3,400 mmG+33,380, 3,400 and 3,070 mm
Above the top floor, as orderedG+1Set to your houseG+23,670 mmG+33,648 mm
Across the range
Ride
- Speed
- About 0.2 m/s
- Capacity
- 450 kg
- Noise
- About 60 dB
- Drive
- Electric cylinder
- Power
- 3 kW
- Machine room
- Not needed
Shaft
- Frame
- 75 × 35 mm aluminium, champagne
- Glass
- 5 mm tinted
- Infill
- Aluminium panels
- Size
- Drawn to your house
- Pit
- None: a 5-inch recess sets the car flush with the floor
- Headroom
- Measured at the site survey
Car and doors
- Car walls
- Stainless steel or tempered glass
- Landing doors
- Electric outward swing or manual sliding
- Door opening
- 720 × 2,000 mm, or 1,085 mm on a wide shaft
- Door lighting
- Warm LED strips
- Controls
- Touchscreen panel
Assurance
- Installation
- By Amty’s own team, in 30 days
- Service
- Amty technicians only
- Quality system
- ISO 9001-certified manufacturer
- Warranty
- One year, free
Included
- Site survey
- Supply, installation and commissioning by our own team
- Car walls in stainless steel or tempered glass
- One-year warranty
